FaceX NextGen – The Future of Facial Recognition Access Control (4G)
The FaceX Facial Recognition Access Control 4G system represents the next evolution in biometric security and workforce management. Powered by advanced AI algorithms and 4G connectivity, FaceX delivers fast, secure, and fully contactless authentication for modern organizations.
Designed to manage up to 20,000 registered users, this intelligent facial recognition access control solution ensures seamless verification in high-traffic environments while maintaining industry-leading accuracy and security standards.
With IP65-rated protection, AI-based liveness detection, and long-range face recognition up to 3 meters, FaceX is built for both indoor and outdoor deployments.
Intelligent AI Facial Recognition with 4G Connectivity
The FaceX Facial Recognition Access Control 4G terminal integrates dual 2MP RGB and IR cameras with an intelligent face-matching engine. Its advanced liveness detection technology prevents spoofing attempts using photos or videos, ensuring only real human faces are authenticated.
Powered by the RV1109 Dual-Core A7 processor, the system performs 1:N matching in under one second, enabling smooth entry even during peak traffic hours.
With integrated Ethernet, Wi-Fi, and optional 4G SIM support, the device ensures uninterrupted communication and real-time synchronization with central servers or cloud-based platforms — ideal for remote sites and distributed facilities.
An optional thermal screening module measures temperature with ±0.3°C accuracy from up to 3 meters, making it suitable for healthcare facilities, industrial environments, and public installations.
Built for Durability and Large-Scale Deployments
FaceX is engineered for demanding environments. The IP65 waterproof and dustproof design ensures consistent operation in harsh weather conditions, while its slim 2cm ultra-thin body combines durability with a modern aesthetic.
Supporting up to 20,000 face templates, the system scales effortlessly from SMEs to enterprise-level organizations. The 7-inch IPS HD capacitive touchscreen delivers a responsive and user-friendly interface, while the Linux 4.19 operating system ensures stable and secure performance.
Low power consumption (<15W) and DC 12V/2A input make it energy efficient and environmentally responsible.
Flexible Authentication & Smart Integration
The FaceX Facial Recognition Access Control 4G system supports:
- Face Recognition
- Contactless Smart Card
- Multi-factor authentication
Its GPIO expansion ports allow seamless integration with:
- Door locks
- Exit buttons
- Fire alarm systems
This makes it ideal for smart buildings, industrial sites, warehouses, and high-security zones requiring centralized monitoring and access control automation.
Cloud-Based Attendance & Workforce Management
FaceX integrates effortlessly with cloud-based attendance and payroll software. Administrators can:
- Monitor attendance in real-time
- Generate reports instantly
- Manage shift schedules
- Automate payroll processing
- Track remote employees
The 4G capability ensures data synchronization even in remote areas without a wired network infrastructure.
The system also supports mobile attendance applications with GPS tagging, selfie capture, and automated email reporting — perfect for field staff and on-the-move workforce management.
Reliable Performance Across All Climates
Operating temperature range: -20°C to +60°C
Humidity tolerance: Up to 90% non-condensing
Whether installed at factory entrances, corporate offices, gated communities, or outdoor checkpoints, FaceX maintains consistent, secure performance.
Technical Specifications
| Item | Specification |
|---|---|
| Chipset | RV1109 Dual core A7, 1.5GHz |
| Authentication Modes | Face Recognition / Contactless Card |
| RGB Camera | 2MP 1.5mm 117° |
| IR Camera | 2MP 1.5mm 117° |
| Thermal Infrared Camera (Optional) | 160X120 Field View Angle 40° |
| Temp. Measuring Range | 0°C ~ 50°C |
| Temp. Measuring Distance / Accuracy | < 3m / ± 0.3°C |
| Stranger Access Mode | Normal Temperature Allow / Deny Access |
| FAR (False Acceptance Ratio) | 0.0001% |
| FRR (False Rejection Ratio) | 0.01% |
| Authentication Time | Less than 1 second |
| Storage Capacity | 1GB RAM & 4GB ROM (Upgradable) |
| User Limit | 20,000 |
| Operating System | Linux 4.19 |
| Communication Methods | Ethernet 10/100Mbps, SIM Card 4G |
| GPIO | Door Lock, Exit Button, Fire Alarm |
| Display | 7” IPS HD Capacitive Touchscreen |
| Power | 12V DC, < 15W |
| Card Reader | Contactless Smart Cards (2.5–5cm) |
| Temperature Tolerance | -20° ~ +60° C |
| Humidity | 20% ~ 90% (Non-Condensing) |
| Acoustics | 1W Built-in Speaker |
| Watchdog | Auto-restart on Failure |
| Dimensions | 220 × 115 × 20 mm (990 gms) |
Secure, Scalable & Future-Ready
The FaceX Facial Recognition Access Control 4G system combines intelligent AI hardware with cloud-enabled software to deliver enterprise-grade security and attendance management.
With 4G connectivity, AI-powered liveness detection, IP65 durability, and support for 20,000 users, FaceX is the ideal solution for organizations seeking reliable, future-ready biometric access control.
Upgrade to smarter security with Facial Recognition Access Control 4G — built for performance, scalability, and modern workforce automation.
